Model
100Ah 25.6V
200Ah 25.6V
300Ah 25.6V
Basic Information
Nominal Voltage
25.6VDC
Voltage Range
20V-29.2V
Nominal Capacity
100Ah
300Ah
Rated Capacity
2.56kWh
7.68kWh
Max. Number of Parallel Connections
2
15
Cycle Life
6000 cycles (25℃@80% DoD)
Protection Mechanism
Temperature Protection/Over-current Protection/Short-circuit ProtectionOver-charge Protection/Over-discharge Protection/Low-voltage Protection
Charging Parameters
Recommended Charging Current
50A
75A
Max. Charging Current
100A
150A
Recommended Charging Voltage
29V
Max. Charging Voltage
29.2V
Discharging Parameters
Recommended Discharging Current
Max. Discharging Current
Recommended Battery Discharge Cut-off Voltage
22V
Battery Cut-off Voltage
20V
General Parameters
Dimension
450*325*168mm
495*380*245mm
580*440*245mm
Protection Rating
IP20
Net Weight
23kg
62KG
Shell Material
Sheet Metal
Product Functions
Communication
Bluetooth
Certification & Safety Standard
Certification
CE/MSDS/UN38.3
Temperature Parameters
Discharging Temperature
-20~60℃
Charging Temperature
0~55℃
Storage Temperature
-20~45℃
