Lithium Battery Outdoor Cabinet 204kwh-241kwh 价格：元

ModelSystem CompositionRated Voltage (V)Operating Voltage (V)Rated Energy (kWh)

Dimensions(D*W*H)mm

Weight(t)
GSS-PC44pack204.8192~227.264.31300*750*16750.9
GSS-PC55pack256240~28480.41300*750*19301.0
GSS-PC66pack307.2288~340.896.51300*750*21851.1
GSS-PC77pack358.4336~397.6112.51300*1183*14201.5
GSS-PC88pack409.6384~454.4128.61300*1183*16751.7
GSS-PC99pack460.8432~511.2144.7
1.8
GSS-PC1010pack512480~568160.81300*1183*19302.0
GSS-PC1111pack563.2528~624.8176.8
2.1
GSS-PC1212pack614.4576~681.6192.91300*1183*21852.3
GSS-PC1313pack665.6624~738.4209.0
2.4
GSS-PC1414pack716.8672~795.2225.11300*1183*24402.5
GSS-PC1515pack768720~852241
2.6
Details

General Parameters

ModelSystem CompositionRated Voltage (V)Operating Voltage (V)Rated Energy (kWh)Dimensions(D*W*H)mmWeight(t)
GSS-PC44pack204.8192~227.264.31300*750*16750.9
GSS-PC55pack256240~28480.41300*750*19301.0
GSS-PC66pack307.2288~340.896.51300*750*21851.1
GSS-PC77pack358.4336~397.6112.51300*1183*14201.5
GSS-PC88pack409.6384~454.4128.61300*1183*16751.7
GSS-PC99pack460.8432~511.2144.7
1.8
GSS-PC1010pack512480~568160.81300*1183*19302.0
GSS-PC1111pack563.2528~624.8176.8
2.1
GSS-PC1212pack614.4576~681.6192.91300*1183*21852.3
GSS-PC1313pack665.6624~738.4209.0
2.4
GSS-PC1414pack716.8672~795.2225.11300*1183*24402.5
GSS-PC1515pack768720~852241
2.6


System Parameters

Cell ParametersCell TypeLitdium Iron Phosphate Cell
Cell Specification3.2V314Ah
PACK ParametersCombination Mode16S1P
Rated Voltage (V)51.2
Operating Voltage (V)48~56.8
Rated Energy (kWh)16
System ParametersStandard Charge/Discharge Power0.5P
Maximum Charge/Discharge Rate0.5P
Protection & General ParametersDC Overcurrent ProtectionYes
DC Short - Circuit ProtectionYes
DC Overvoltage ProtectionYes
Over - temperature ProtectionYes
Fire - fighting SystemAerosol/Perfluoroketone Optional
Wiring ModeSide - entry Wiring
Ambient Temperature (°C)-20~50 (>45 requires derating)
Charging Temperature (°C)0~55
Discharging Temperature (°C)-10~55
Ambient Humidity (%RH)<95, No Condensation
Operating Altitude (m)5000 ( Derated use above 2000m)
Protection ClassIP54(Key Components IP65)
Cooling MetdodIndustrial Air Conditioning

Note: Subject to tde actual product. If tdere are any modifications to tde parameters, we will not notify separately.
